Public Member Functions
def	__init__ (self, CamphorProjectSchema schema, CamphorNetworkManager networkManager)

None	createDataCenter (self, str name='dc', DeviceOS switchOS=DeviceOS.SONiC, DeviceOS serverOS=DeviceOS.ALPINE, switchVersion=None, bool synchronize=True, int pods=1, int racks=2, int leafs=2, int servers=2, int spines=2, int superSpines=0, int borderLeafs=0, int cores=0, int vpns=0, int evpns=0, int hosts=0, int addresses=0, bool generateDefaultConf=True, UnderlayConnectivity underlay=UnderlayConnectivity.ebgp, OverlayConnectivity overlay=OverlayConnectivity.evpn)
	Create a CLOS design based Data Center Network Topology. More...

DeploymentConfigurationAttributesDefinition	getDeploymentCommonAttributes (self)

None	setDeploymentCommonAttributes (self, DeploymentConfigurationAttributesDefinition attributes)

DeploymentAttributesDefinition	createDeployment (self, str name, Optional[DeploymentConfigurationAttributesDefinition] attributes=None, Pods pods=None, Racks racks=None, ItemLeafs leafs=None, Spines spines=None, Servers servers=None, Cores cores=None, SuperSpines superSpines=None, BorderLeafs borderLeafs=None, RouteReflectors routeReflectors=None, BGPTesters bgpTesters=None)

List[DeploymentAttributesDefinition]	getDeployment (self)

int	findDeploymentPosition (self, str name)

DeploymentAttributesDefinition	findDeployment (self, str name)

None	deleteDeployment (self, str name)

Public Attributes
	schema

	networkManager

Detailed Description

Definition at line 18 of file camphor_deployment_manager.py.

Constructor & Destructor Documentation

◆ init()

def __init__	(		self,
		CamphorProjectSchema	schema,
		CamphorNetworkManager	networkManager
	)

Definition at line 19 of file camphor_deployment_manager.py.

Member Function Documentation

◆ createDataCenter()

None createDataCenter	(		self,
		str	name = `'dc'`,
		DeviceOS	switchOS = `DeviceOS.SONiC`,
		DeviceOS	serverOS = `DeviceOS.ALPINE`,
			switchVersion = `None`,
		bool	synchronize = `True`,
		int	pods = `1`,
		int	racks = `2`,
		int	leafs = `2`,
		int	servers = `2`,
		int	spines = `2`,
		int	superSpines = `0`,
		int	borderLeafs = `0`,
		int	cores = `0`,
		int	vpns = `0`,
		int	evpns = `0`,
		int	hosts = `0`,
		int	addresses = `0`,
		bool	generateDefaultConf = `True`,
		UnderlayConnectivity	underlay = `UnderlayConnectivity.ebgp`,
		OverlayConnectivity	overlay = `OverlayConnectivity.evpn`
	)

Create a CLOS design based Data Center Network Topology.

Data Centers are one of the most commonly deployed and managed network. Typically, CLOS based network topology is used in forming modern data centers. Using this API to readily instantiate one such!

Parameters

[in]	name	str Name of the datacenter
[in]	switchOS	DeviceOS(DeviceOS.SONiC) Type of the Switches' Network Operating System (NOS)
[in]	serverOS	DeviceOS(DeviceOS.ALPINE) Type of the Servers'' Operating System (OS)
[in]	pods	Number of pods
[in]	racks	Number of racks
[in]	leafs	Number of leafs
[in]	servers	Number of servers
[in]	spines	Number of spines
[in]	superSpines	Number of superSpines
[in]	borderLeafs	Number of borderLeafs
[in]	cores	Number of cores
[in]	vpns	Number of vpns
[in]	evpns	Number of evpns
[in]	hosts	Number of hosts
[in]	addresses	Number of addresses

#
# Copyright (C) Camphor Networks, Inc - All Rights Reserved
# Unauthorized copying of this file via any medium is strictly prohibited
# Proprietary and confidential
# Written by Ananth Suryanarayana <ananth@camphornetworks.com>, June 2021
# https://camphornetworks.com/camphor-networks-platform-terms-of-use-and-privacy-policy/
# mailto:info@camphornetworks.com?subject=copyright
#
# yaml-language-server: $schema=/var/lib/camphor/camphor_project_schema.json
#
# Run this command from any camphor cluster node to load this topology!
# export CAMPHOR_PASSWORD='<CamphorPassword>'
# python3 /var/lib/camphor/camphor_api/camphor_manage_device.pyc --oper=load-deployment <yaml-file>
#
---
deployments:
  attributes:
    deviceAttributes:
      os: SONiC
    leafAttributes:
      leafs: 2
    podAttributes:
      pods: 1
    rackAttributes:
      racks: 2
    serverAttributes:
      deviceAttributes:
        os: ALPINE
      servers: 2
    spineAttributes:
      spines: 2
  item:
  - attributes:
      deploymentAttributes:
        type: datacenter
    name: dc

Definition at line 50 of file camphor_deployment_manager.py.

References CamphorDeploymentManager.createDeployment(), CamphorDeploymentManager.networkManager, CamphorManager.networkManager, and CamphorDeploymentManager.setDeploymentCommonAttributes().

Here is the call graph for this function:

◆ getDeploymentCommonAttributes()

DeploymentConfigurationAttributesDefinition getDeploymentCommonAttributes ( self )

Definition at line 80 of file camphor_deployment_manager.py.

References CamphorApplicationManager.schema, CamphorBgpTesterManager.schema, CamphorClusterManager.schema, CamphorDeploymentManager.schema, CamphorDeviceManager.schema, CamphorManager.schema, CamphorMetricManager.schema, CamphorMonitorManager.schema, CamphorNetworkManager.schema, CamphorProjectManager.schema, and CamphorTableManager.schema.

◆ setDeploymentCommonAttributes()

None setDeploymentCommonAttributes	(		self,
		DeploymentConfigurationAttributesDefinition	attributes
	)

Definition at line 83 of file camphor_deployment_manager.py.

References CamphorApplicationManager.schema, CamphorBgpTesterManager.schema, CamphorClusterManager.schema, CamphorDeploymentManager.schema, CamphorDeviceManager.schema, CamphorManager.schema, CamphorMetricManager.schema, CamphorMonitorManager.schema, CamphorNetworkManager.schema, CamphorProjectManager.schema, and CamphorTableManager.schema.

Referenced by CamphorDeploymentManager.createDataCenter().

Here is the caller graph for this function:

◆ createDeployment()

DeploymentAttributesDefinition createDeployment	(		self,
		str	name,
		Optional[DeploymentConfigurationAttributesDefinition]	attributes = `None`,
		Pods	pods = `None`,
		Racks	racks = `None`,
		ItemLeafs	leafs = `None`,
		Spines	spines = `None`,
		Servers	servers = `None`,
		Cores	cores = `None`,
		SuperSpines	superSpines = `None`,
		BorderLeafs	borderLeafs = `None`,
		RouteReflectors	routeReflectors = `None`,
		BGPTesters	bgpTesters = `None`
	)
